D-Link DSL-520B User Guide

Section 3 – Configuration
Statistics
To access the Router’s first Statistics window, click the Statistics link in the Device Info directory.
Click the LAN link to view the Router’s LAN statistics. Click the Reset
Statistics button to refresh these statistics.
Click the WAN link to view the Router’s WAN statistics. Click the Reset
Statistics button to refresh these statistics.
Click the ATM link to view Router’s ATM statistics. Click the Reset button
to refresh these statistics.
D-Link DSL-520B User Manual
19

D-Link DSL-520B Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Interfaces

ADSL interface	RJ-11 connector
LAN interface	RJ-45 port
Ethernet	10/100BASE-T
