Section 3 – Configuration
NAT
The NAT setup window allows you to configure Virtual Server settings, Port Triggering and a DMZ host.
To configure virtual server settings, click the Virtual Servers link.
Click the Add button to add a new a new virtual server service.
Select a Service from the drop-down menu or click the Custom Server
radio button to create a custom service.
You can also configure the External Port Start, External Port End,
Protocol, Internal Port Start, Internal Port End and Remote IP settings
for the service you want to setup on your Router.
When you have finished configuring the virtual server click the
Save/Apply button.
D-Link DSL-520B User Manual
35
