Section 3 – Configuration
MAC Filtering
The Router MAC Filtering function is only effective on ATM PVCs configured in Bridge mode. The Router supports two policies for MAC Filtering,
Forwarded or Blocking. Setting a Forwarded policy means that all MAC layer frames will be forwarded except the MAC layer frames that are listed
in the MAC Filtering table. Setting a Blocked policy means that all MAC layer frames will be blocked except the MAC layer frames that are listed in
the MAC Filtering table.
To access the MAC Filtering window, click the MAC Filtering Link.
.
This window allows you to set up MAC Filtering on the Router.
Click the Change Policy button to change between a Forwarded or
Blocked MAC Filtering Global Policy.
Click the Add button to add a new MAC filter. Choose the Protocol type
from the drop-down menu, type the Destination MAC Address, type the
Source MAC Address and choose the Frame Direction from the drop-
down menu. Tick the WAN interfaces you want to apply the policy to.
When you have finished configuring the MAC filter, click the Save/Apply
button.
To remove a MAC filter tick the check box next to the MAC filter rule you
want to remove and click on the Remove button.
D-Link DSL-520B User Manual
40
