Section 3 – Configuration
TR-069 Client
TR069 is a WAN Management Protocol that allows an Auto-Configuration Server (ACS) to perform auto-configuration, provision, collection and
diagnostics to the router. To access the TR-069 window, click the TR-069 link in the Management directory.
To configure TR-069 carry out the following:
! Select whether to Enable or Disable the Inform message by clicking
the Enable or Disable radio button.
! Type in the amount of time in seconds for the interval you want to be
informed about TR069 messages in the Inform Interval field.
! Type in the URL of the ACS server you want to use to carry out the
auto-configuration, provision, collection and diagnostics to the
device in the ACS URL field.
! Type in the User Name you will use to log onto the ACS server, into
the ACS User Name field.
! Type in the Password you will use to log onto the ACS server, into
the ACS Password field.
! If you require the ACS server to authenticate to your Router, tick the
Connection Request Authentication checkbox.
! Two text boxes will appear
! Type in the User Name you want the Auto Configuration Server to
login with in the Connection Request User Name field.
! Type in the Password you want the Auto Configuration Server to
login with in the Connection Request Password field.
Click the GetRPCMethods button to populate the TR-069 settings automatically from the tot ISP.
When you have finished configuring the TR-069 settings, click the Save/Apply button.
D-Link DSL-520B User Manual
54
