Section 3 – Configuration
Filters
Parameter
Description
Filter Name Enter a name for the new filter.
Protocol Select the transport protocol from the drop-down menu (TCP/UDP, TCP, UDP or ICMP) that will be used for the filter rule.
Source IP
Address
Enter the source IP address which you are creating the filter rule for.
Source Subnet
Mask
Enter the subnet mask for the source IP address you are creating the filter rule for.
Source Port
(port or
port:port)
The Source Port is the TCP/UDP port on either the LAN or WAN depending on if you are configuring an Outbound or Inbound
Filter rule.
Destination IP
Address
Enter the destination IP address which you are creating the filter rule for.
Destination
Subnet Mask
Enter the subnet mask for the destination IP address you are creating the filter rule for.
Destination Port The Destination Port is the TCP/UDP port on either the LAN or WAN depending on if you are configuring an Outbound or
Inbound Filter rule.
IP Filtering – Incoming
The Inbound Filter allows you to create a filter rule to allow incoming IP
traffic by specifying a filter name and at least one condition on this
window. All of the specified conditions in this filter rule must be satisfied
for the rule to take effect. By default, all incoming IP traffic from the
Internet is blocked when the firewall is enabled.
If you are setting up the incoming IP filtering, click the Incoming link, then
click the Add button.
D-Link DSL-520B User Manual
38
