D-Link DSL-5300 - Hardware Overview; Connections

6D-Link DSL-5300 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 2 3 64
5
7 8 9
1 DSL Port Connect to a DSL-enabled telephone line with the supplied microlter/splitter.
2 USB 3.0 Port Connect a USB ash drive to share content or connect it to a USB printer to share it on your network.
3 USB 2.0 Port Connect a USB ash drive to share content or connect it to a USB printer to share it on your network.
4 Reset Button Insert a paperclip in the hole and wait for several seconds to reset the router to default settings.
5 WPS Button Press to start the WPS process and automatically create a secure connection to a WPS client.
6 Gigabit WAN Port Connects to Ethernet WAN devices.
7 Gigabit LAN Ports (1-4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
8 Power Button Press the power button to turn the router on or o.
9 Power Connector Connector for the supplied power adapter.
