24D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 4 - Conguration
Protocol: Select the protocol type MAC Encapsulation Routing (MER), PPP
over Ethernet (PPPoE), or Bridging from the dropdown menu.
Multiple Vlan: If you wish to Enable Multiple Vlan Over One Connection, check
the box.
802.1P Priority
[0-7]:
Enter the 802.1P priority number.
802.1Q VLAN ID
[0-4094]:
Enter the VLAN ID.
CONNECTION TYPE
If you are adding an Ethernet WAN connection you will be presented with the
following conguration options.
Add an Ethernet WAN Connection
