D-Link DSL-G225 User Manual

86D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 4 - Conguration
Static Route
Destination
Network Address:
Enter the destination address.
Subnet Mask Enter the subnet mask.
Use Gateway IP
Address:
Enter the Gateway IP address.
Use Interface Select the correct interface for the rule.
STATIC ROUTE ADD
ROUTING  STATIC ROUTE
To congure a static route, click Static Route.
You will see a list of current routes. Click Add to open the Static Route Add panel.
Click Apply when you are done.

D-Link DSL-G225 Specifications

Power

input voltage	100~240 V
input frequency	50~60 Hz
output voltage	DC 12 V

Operating Environment

operating temperature	0 to 40 °C
non-operating temperature	-20 to 65 °C
operating humidity	0% - 90% non-condensing

Weight and Dimensions

dimensions	131.5 x 74.3 x 185.4 mm
weight	285 grams
