DIR-620S Wireless N300 Router with 3G/LTE Support and
USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Ports
Select a type for each port included in the VLAN.
• Untagged: Untagged traffic will be transmitted through the
specified port.
• Tagged: Tagged traffic will be transmitted through the
specified port. If at least one port of this type is included to
the VLAN, it is required to fill in the VLAN ID and QoS
fields.
Leave the Excluded value for the ports not included in the VLAN.
Wireless interfaces
Select the Untagged value for each Wi-Fi interface included in the
VLAN.
Leave the Excluded value for the Wi-Fi interfaces not included in
the VLAN.
Click the APPLY button.
To edit an existing VLAN, select the relevant line in the table. On the page displayed, change the
parameters and click the APPLY button.
To remove an existing VLAN, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ).
Page 171 of 238
