DIR-620S Wireless N300 Router with 3G/LTE Support and
USB Port
User Manual
Installation and Connection
Connecting to PC
PC with Ethernet Adapter
1. Connect an Ethernet cable between any of LAN ports located on the back panel of the router
and the Ethernet port of your PC.
2. To connect via USB modem: connect your USB modem to the USB port
5
located on the side
panel of the router.
!
In some cases you will need to reboot the router after connection of the USB modem.
3. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
4. Turn on the router by pressing the POWER button on its back panel.
Then make sure that your PC is configured to obtain an IP address automatically (as DHCP client).
5 It is recommended to use a USB extension cable to connect a USB modem to the router.
Page 21 of 238
