DIR-620S Wireless N300 Router with 3G/LTE Support and
USB Port
User Manual
Configuring via Web-based Interface
Configuring Wired WAN Connection
This configuration step is available for the Router and WISP Repeater modes.
!
You should configure your WAN connection in accordance with data provided by your
Internet service provider (ISP). Make sure that you have obtained all necessary information
prior to configuring your connection. Otherwise contact your ISP.
1. On the Internet connection type page, click the SCAN button (available only for the
Router mode) to automatically specify the connection type used by your ISP or manually
select the needed value from the Connection type list.
2. Specify the settings necessary for the connection of the selected type.
3. If your ISP uses MAC address binding, select the Clone MAC address of your device
checkbox (available only for the Router mode).
4. If the Internet access is provided via a VLAN channel, select the Use VLAN checkbox and
fill in the VLAN ID field (available only for the Router mode).
5. Click the NEXT button to continue or click the BACK button to return to the previous page.
Page 56 of 238
