ENGLISH
45
Increases the current parameter (if it is an editable parameter).
Table 5
Holding down the “˄” key or the “˅” key allows the automatic increase/decrease of the parameter selected. After the “˄” key or the “˅” key has
been held down for 3 seconds, the automatic increase/decrease speed increases.
When the ˄ key or the ˅ key is pressed the selected value is modified and saved immediately in the permanent memory (EEprom).
If the machine is switched off, even accidentally, in this phase it does not cause the loss of the parameter that has just been set.
The SET key is only for leaving the current menu and is not necessary for saving the changes made. Only in particular cases
described in the following paragraphs are some values updated by pressing “SET” or “MODE”.
Warning leds
• Power
White led. Lit with a fixed light when the machine is powered. Blinking when the machine is disabled.
• Alarm
Red led. Lit with a fixed light when the machine is blocked by an error.
Menus
The complete structure of all the menus and of all the items of which they are composed is shown in Table 7.
Access to the menus
The various menus can be accessed from the main menu in two ways:
1. Direct access with a combination of keys.
2. Access by name with a drop-down menu.
4.1 Direct Access with a Combination of Keys
The desired menu can be accessed directly by pressing simultaneously the appropriate combination of keys for the required time (for example
MODE SET to enter the Setpoint menu) and the various items in the menu are scrolled with the MODE key.
Table 6 shows the menus that can be reached with the combinations of keys.
User
On releasing the button
Monitor
2 Sec
Setpoint
2 Sec
Manual
3 Sec
Installer
3 Sec
Technical assistance
3 Sec
Reset factory values
2 sec after switching on appliance
Reset
2 Sec
Table 6
