DAB esybox mini3 User Manual

ENGLISH
55
Alarm in the fault log
Identifying code
Description
PD
(1)
Irregular switching off
HL
(1)
Alarm giving advance warning of Hot Fluid Blockage
OT
Alarm giving advance warning of Blockage due to overheating of the power
amplifiers
OBL
Alarm indicating abnormal temperature recorded on the Low Voltage board
AYS
(2)
“Anti Cycling Smart” function running
AE
(2)
“Anti Block” function running
AF
(2)
“Anti Freeze” function running
BAT
(2)
Low battery
Table 15: Fault description
Blockage conditions
Display indication
Description
PH
Cutout due to pump overheating
BL
Blockage due to water lack
BP1
Blockage due to reading error on the delivery pressure sensor
BP2
Blockage due to reading error on the suction pressure sensor
PB
(1)
Blockage due to supply voltage outside specifications
LP
Block for low DC voltage
HP
Block for high DC voltage
OT
Blockage due to overheating of the power stages
OC
(1)
Blockage due to motor overload
SC
Blockage due to short circuit between the motor phases
ESC
Blockage due to short circuit to earth
HL
Hot Fluid Blockage
NC
Blockage due to motor disconnected
E
i
Blockage due to i-th internal error
V
i
Blockage due to i-th internal voltage out of tolerance
EY
Block for cyclicality abnormal detected on the system
Table 16: Indications of blockages
6.1 - Description of blockages
6.1.1 - “BL” Anti Dry-Run (Protection against dry running)
In the case of lack of water the pump is stopped automatically after the time TB. This is indicated by the red “Alarm” led and by the letters “BL” on
the display. After having restored the correct flow of water you can try to leave the protective block manually by pressing the “˄” and “˅“ keys
simultaneously and then releasing them. If the alarm status remains, or if the user does not intervene by restoring the flow of water and resetting
the pump, the automatic restart will try to restart the pump.
If the parameter SP is not correctly set, the protection against water lack may not work correctly.
6.1.2 - Anti-Cycling (Protection against continuous cycles without utility request)
If there are leaks in the delivery section of the plant, the system starts and stops cyclically even if no water is intentionally being drawn: even just
a slight leak (a few ml) can cause a fall in pressure which in turn starts the electropump.
The electronic control of the system is able to detect the presence of the leak, based on its recurrence.
The Anti-Cycling function can be excluded or activated in Basic or Smart mode (par 5.6.6).
In Basic mode, once the condition of recurrence is detected the pump stops and remains waiting to be manually reset. This condition is
communicated to the user by the lighting of the red “Alarm” led and the appearance of the word “ANTICYCLING” on the display. After the leak
has been removed, you can manually force restart by simultaneously pressing and releasing the “˄” and “˅“ keys.
In Smart mode, once the leak condition is detected, the parameter RP is increased to decrease the number of starts over time.
6.1.3 - Anti-Freeze (Protection against freezing of water in the system)
The change of state of water from liquid to solid involves an increase in volume. It is therefore essential to ensure that the system does not remain
full of water with temperatures close to freezing point, to avoid breakages of the system. This is the reason why it is recommended to empty any
electropump that is going to remain unused during the winter. However, this system has a protection that prevents ice formation inside by activating
the electropump when the temperature falls to values close to freezing point. In this way the water inside is heated and freezing prevented.
