8-4. Actual load calibration
This is a calibration method by adding actual load on the sensor. Standard weight is Needed.
Displays Shunt CAL Value (Please write to S.CAL)
DATE Rated output S.CAL
22
Measuring mode
While key is being pressed, Press key
Displays Function Mode State
Displays Sensor Ouput Value Calibration State
Displays Actual Load Calibration State
Displays the acual load State
Input the actual load (standard weight) by using and
key. And then press key.
Calibration Completed
Displays Zero State
Press
key without adding any load on the sensor.
About 1 second later,
After adding the actual load (standard weight) on the sensor,
press key
After about 1 sec for
Displays the Rated output value input state
Input the rated output value by using and key. And then,
press
key. (In
p
ut 3.0000 if donot know the rated out
p
ut of
sensor)
