dacell DN-100 User Manual

3. Specification
Specification model
DN-100 DN-150 DN-200 DN-250
SIGNAL 1 ~ 3mV/V
ANALOG OUT DC 0 ~ 10V ( 4 ~ 20mA)
EXCITATION 5V
Available
sensor
Strain Gauge sensor (Bridge 120Ω, 350Ω, 700Ω)
Upper limit
Display
-19999 ~ +99999
A/D Converter 16bit, 5000 times/sec 24bit 1000 times/sec
D/A Converter 16bit, 1000 times/sec
ZERO 0.5μV/℃
Temper
ature
Charact
eristic
SPAN 50ppm/℃
Measured value
display
7 segment LED 14mm
Status display
LED
Red LED 6 pcs
Hi, Lo display 7 segment LED 10mm X 7 segment LED 10mm X
Key Switch 4 pcs
Comparison output Upper limit(HI), Lower limit(LO), Normal(OK) Output(4 Realy)
Contact Capacity AC 250V 5A
Temperature
range for use
-10℃~ 60, >80% RH (No dewing)
Weight about 600g
Power supplay AC 90 ~ 240V, 50/60㎐
OPTION OP-01 : BCD, OP-02 : RS232C, OP-03 : RS485, OP-04 : RS422
External dimension 97 × 97 × 141 mm (W × H × D)
Panel cutting size 92.5 × 92.5 mm
