SPECIFICATIONS
3
3
-
5
※
The specications are subject to change without notice.
ITEM
MODEL
DK4510 DK5010 DK5510
Hydraulic
system
Max. lifting capacity
kgf (lbs.)
From 24 in. (61 cm) Behind 1,232 (2,716)
Under lower link 1,360 (2,998)
Number of External Hydraulic valves 1 (2EA)
PTO
Rear
Type Independent
PTO shaft SAE 1-3/8, 6 Spline
Speed rpm
540 / 750
Min. turning radius
(with one rear wheel braked)
m -
Weight (with ROPS) kg (lbs.) -
Draw-
bar
Max. Drawbar vertical load kg (lbs.) 750 (1,655)
Max. Trailer loading weight
kg (lbs.) 4,300 (9,480)
Optional
7-pin socket
○
Front work light
○
Rear work light
○
SMV sign
○
