TACHOMETER/HOURMETER ECO PTO
(1) 540 rpm
FUEL GAUGE
(1) Fuel Gauge
E: Empty F: Full
This gauge indicates the remain-
ing fuel level after the key switch is
turned to the “ON” position.
• F: Fuel is fully lled.
• E: Replenish the fuel tank.
If driving is continued with the needle
below the position “E”, air may enter
the fuel supply system. In this case,
“bleed” the system. (For detailed in-
structions, refer to “Bleeding fuel sys-
tem” in the chapter “Maintenance”)
(1) Tachometer (2) Hourmeter
The tachometer indicates the engine
rpm.
The hour meter indicates the total
run hours of the tractor in 6 digits.
The last digit represents 1 hour.
The hourmeter does not operate if
the engine is stopped even if the key
switch is in the "ON" position.
The PTO speed can be selected as
desired according to the operating
condition.
The PTO speed (
540
) corresponds to
the engine speed for the mid range
load to achieve 540 PTO RPM with
the PTO shift lever in the 1st speed
position (540 RPM).
Set the engine speed around this
mark for efcient and rapid work.
td2O416b
td2O417b td2O418b
