DK4510 / DK5010 / DK5510
OPERATING THE CONTROLS
(1) Shuttle Shift Lever
(2) Hand Throttle Lever
(3) Parking Brake Lever
(4) Clutch Pedal
(5) brake Pedal (LH)
(6) brake Pedal (RH)
(7) Foot Throttle
(8) Main Shift Lever
(9) Range Shift Lever
(10) Lift Position Control Lever
(11) Draft Load Control Lever
(12) One-touch Lifting/Lowering Lever
(13) PTO Shift Lever
(14) Tilt Control Lever
(15) PTO Switch
1
4
14
9
13
2
5 6
7
3
8
12
10
15
11
1
4
14
9
13
2
5 6
7
3
8
12
10
15
11
