Daewoo FR-521 - TOTAL PARTS LIST (FR-521,551 NT;NB)

23
2. TOTAL PARTS LIST ( FR-521,551NT/NB )
is a recommendable part for essential stock.
NO PART CODE PART NAME PART DESCRIPTION QUANTITY REMARK
1 3010074930 ASSY CAB URT FRP-440 1
3010074940 ASSY CAB URT FRP-440(HCFC)
3010074830 ASSY CAB URT FRP-480 1
3010074940 ASSY CAB URT FRP-480(HCFC)
2 3012905400 HINGE *T SCP1, T2.3 1
3 3016001230 SPECIAL BOLT T/U 6 X 22 SWCH22A(WH) 3
4 3011429000 COVER *T HI PP 1
5 3010519800 BOX MAIN POWER PP 1
6 PCB MAIN AS 1 REFER TO #17
7 TRANS POWER 1 REFER TO #16
10 HARNESS RUN CON 1
11 CAPACITOR RUN 1 REFER TO #13
12 3011444900 COVER M-PCB BOX P.P 1
13 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 2
14 3012905801 HINGE *M AS PO T3.2, FRB-5460CT 1
14-1 3011424700 COVER *M HI ABS 1
15 3016001220 SPECIAL BOLT M
6 X 20 SWCH22A(WH)
3
16 3012102900 FOOT * F * L AS 1
17 3012103000 FOOT * F * R AS 1
18 3016000700 SPECIAL SCREW M6 X 15 2
19 3012101500 FOOT ADJ AS FRB-5350NB 1
20 3012102500 FOOT ADJ * L AS FRB-5350NB 1
21 3012906410 HINGE * U AS FRB-5460CT 1
22 3016005300 SPECIAL WASR S10C T1.5 1
23 3016001230 SPECIAL BOLT T/U 6 X 22 SWCH22A(WH) 3
24 3011439900 COVER CAB BRKT PP 1
25 7112401211 SCREW TAPPING
T1 TRS 4 X 12 MFZN
2
26 3010103700 ABSORBER SUC P NR 1
27 CORD POWER AS 1 REFER TO #19
28 7112401211 SCREW TAPPING
T1 TRS 4 X 12 MFZN
1
29 7001400865 SCREW MACHINE PAN 4 X 8 BSNI 1
31 3013202700 HOSE DRN B PP 1
32 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 6
33 3012401410 GRILLE SBHGI T0.4 1
34 7112401211 SCREW TAPPING
T1 TRS 4 X 12 MFZN
2
35 3014426900 PLT WICON AS FLTT SW D4.76 1
EXPLODED VIEW AND PARTS LIST
R
R
R
R
