90 3018904300 LOUVER R *S *L PP 1
91 3013324301 INSULATOR R *S *L F-PS 1
92 7112401611 SCREW TAPPING TRS 4 X 16 MFZN 2
93 3018904400 LOUVER R *S *R PP 1
94 3013324401 INSULATOR R *S *R F-PS 1
95 3010916800 CAP RETUN DUCT ABS 2
96 3011900600 FILTER DEO CUBIC 6
97 3018701400 DEODRANT ANTI CUBIC 6
98 3015502800 WINDOW R GPPS 1
99 LAMP AS 2 REFER TO #16
100 3017901010 SOCKET R LAMP AS 250 [V] / 1 [A] 1
101 7112401611 SCREW TAPPING TRS 4 X 16 MFZN 2
102 3011416800 COVER RETUN DUCT PP 1
103 3019007600 POCKET SM GPPS 2
104 3019007400 POCKET JUMBO GPPS 1
105 3012505700 GUIDE JUMBO POCKET ABS 1
106 3019007500 POCKET EGG GPPS 1
107 3011111600 CASE EGG GPPS 1
108 3012307620 GASKET R DR AS PVC-S 1
109 3019007300 POCKET F*U GPPS 1
110 3019003500 POCKET F*T GPPS 1
111 3012307520 GASKET F DR AS PVC-S 1
112 ASSY F DR FRB-5070NT/NB 1 REFER TO #20
113 ASSY R DR FRB-5070NT/NB 1 REFER TO #21
114 3012610700 HANDLE F FRB-5070NT/NB 1
115 7002501611 SPECIAL SCREW TRS M5X16 MFZN 2
116 3011603400 DECO F DR HNDL FRB-5070NT/NB 1
117 3012610800 HANDLE R FRB-5070NT/NB 1
118 7002501611 SPECIAL SCREW TRS M5X16 MFZN 2
119 3011603400 DECO R DR HNDL FRB-5070NT/NB 1
120 3014532600 PLATE TANK FRB-5070NT/NB 1
121 7173301011 SCREW TAPPING TT2 BIN 3 X 12MFZN 2
122 3014384110 PCB *F AS N808 1
123 3014205500 PANEL *F CONTL ABS 1
124 7125301211 SCREW TAPPING T2S FLT 3 X 10 MFZN 2
125 3016301100 BUTTON FCP *L 1
126 3016301200 BUTTON FCP *R 1
127 3015504600 WINDOW FCP AS FRB-5070NT/NB 1
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
EXPLODED VIEW AND PARTS LIST
