40
73 3011425300 COVER M-PCB BOX PP 1
74 3012904500 HINGE *M T3.2 SCP-1 1
75 3016001220 SPECIAL BOLT *M 6 X 20 SWCH 22A 3
76 3011424700 COVER *M HI ABS 1
77 3010310900 BASE COMP SBHG1-R 1
78 3016500000 CASTER *B PP 2
79 4018S48121 SHAFT CASTER SWRM-10 2
80 3016003300 SPECIAL BOLT T2 6.5 X 20 4
82 3016500700 CASTER F *L AS 1
83 3016500800 CASTER F *R AS 1
84 3016000700 SPECIAL SCREW 2
85 3012101500 FOOT ADJ AS 2
86 3014413710 PIPE WI-CON AS OD4.76 X T0.7 X L28280 1
86-1 DRYER AS OD16 X T0.8 X L135 1 REFER TO #17
87 3011113500 CASE VAPORI PP+CTALC 1
89 3011200500 CLAMP FAN SUS304 1
90 3011800400 FAN OD 110 (ABS) 1 REFER TO #14
91 3011801060 MOTOR C 220 [V] / 60 [Hz] 1 REFER TO #14
92 3012004400 FIXTURE C MOTOR SUC 1
92-1 3010102100 ABSORBER C MOTOR NR 1
93 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 2
94 COMPRESSOR 1 REFER TO #11
95 3010101440 ABSORBER COMP AS 4
96 3016002500 SPECIAL WASR T0.8 SK-5 4
97 SWITCH P-RELAY AS 1 REFER TO #12
98 3012610000 CLAMP BAND RELAY T0.7 SK-4 1
99 CORD POWER AS 1
100 FUSE GLASS TUBE KS NR9A 250 [V] MF51 1 REFER TO #16
101 7001400865 SCREW MACHINE T1 PAN 4 X 12 BSNI 1
102 3013201900 HOSE DRAIN B PP 1
103 3012400400 GRILL SBGH-1 1
104 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 6
105 3010072400 ASSY F DR URT 1
106 3012603200 HANDLE F DR ABS +CR 1
107 7002501211 SCREW MACHINE TRS 5 X 12 MFZN 3
108 3011601500 DECO F DR HNDL ABS 1
109 3014203100 PANEL F CONTROL ABS 1
110 3016000100 SPECIAL WASR T1.5 STS304 1
NO PART CODE PART NAME SPEC QT’ Y REMARK
EXPLODED VIEW AND PARTS LIST
R
R
R
R
R
R
