6
AIR FLOW DIAGRAM
2. FR-780,820NT/NB,860NA
Refrigerator pocket
It is good for the stor-
age of beer and beverage etc.
Freezer pocket
Please don’t put long term storing
items such as ice cream etc.
It might be melted because of
opening the door freguently.
Refrigerator pocket
It is good for the storage of beer
and beverage etc.
Multiple outlet of cooling air.
Please don’t put in vegetable etc.
which contain moisture. It might be
frozen because of low temperature.
Inlet of cooling air
It should not be
blocked with food etc. as it is
the inlet where cooling air
returns.
Crisper
It is suitable to store vegetable
and fruit. The moisture panel which
is attached to the cover maintains
the humidity properly.
Vegetable and fruit would be better to
be packed with clean wrap foils.
Freezer
Pleas don’t put bottles such as beer,
beverage etc.
It might be broken because of freez-
ing.
To Next Page
