39
34-1 3011102501 CASE DEO A PP 1
34-2 3018700700 DEODORANT SHEET 1
34-3 3018700600 DEODORANT 1
34-4 3017714600 SEALING DEO
F-US
1
35 3011441100 COVER CUBIC DUCT HIPS 4
38 3012505400 GUIDE *L AS 1
39 7122401611 SCREW TAPPING T2S TRS 4 X 16 MFZN 1
40 7122401611 SCREW TAPPING T2S TRS 4 X 16 MFZN 1
41 3012505100 GUIDE *R HIPS 1
42 3014700300 ROLLER A POM 1
43 3016003700 SPECIAL WARS OD20 X T2 1
44 3011432500 COVER V/CASE SAN 1
48 3016903500 COVER C-C DUCT AS 1
49 LAMP AS 240 [V] / 15[W] 2 REFER TO #16
50 3017902310 SOCKET R LAMP AS 1
51 3015501600 WINDOW R GPPS 1
52 3017802100 SHELF F SAN 1
53 3014504600 BOX WATER FEED HIPS 1
54 3012501580 GUIDE CHILD DOOR *M SAN 1
55 3012502000 GUIDE CHILD DOOR *R HIPS 1
56 3011104200 CASE CHILD SAN 1
57 30173205400 SHELF W/F TANK PP 1
58 3010017200 SHELF GLASS AS 4
59 3011703400 DOOR CHILD CASE SAN 1 REFER TO #17
59-1 3011701500 DOOR W/F CASE SAN 1
60 3015504400 WINDOW FCP AS 1
61 3011113800 CASE VEGETB A SAN 1
62 3011114200 CASE VEGETB B HIPS 1
63 3014700300 ROLLER A POM 2
64 3011432800 COVER ROLLER A ABS 2
65 3014700400 ROLLER B POM 1
66 3012504900 GUIDE *M ABS 1
67 3010511700 BOX M-PCB PP 1
68 400EL15110 CAPACITOR RUN AC 350[V] / 5 [uF] 1
69 3012715800 HARNESS RUN CON 1
70 SEPK041008 TRANS POWER 1
71 7112401211 SCREW TAPPING T1S TRS 4 X 12 MFZN 3
72 PCB MAIN AS N105 1 REFER TO #17
NO PART CODE PART NAME SPEC QT’ Y REMARK
EXPLODED VIEW AND PARTS LIST
R
R
R
