Daewoo FR-521 - TOTAL PARTS LIST (FR-630,662,700 NT;NB)

28
EXPLODED VIEW AND PARTS LIST
2. TOTAL PARTS LIST ( FR-630,662,700NT/NB )
is a recommendable part for essential stock.
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
1 3010058720 ASSY CAB URT FR-630NT/NB 1 CFC
3010058730 FR-630NT/NB 1 HCFC
3010058820 ASSY CAB URT FR-662NT/NB 1 CFC
3010058830 FR-662NT/NB 1 HCFC
3010058920 ASSY CAB URT FR-700NT/NB 1 CFC
3010058930 FR-700NT/NB 1 HCFC
2 3012905400 HINGE *T T2.3 SCP1 1
3 3011429000 COVER *T HI PP 1
4 3016001230 SPECIAL BOLT T/U M6 X 22 MFZN 4
5 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 5
6 3011444900 COVER M-PCB BOX PP VO 1
7 CAPACITOR RUN 1 REFER TO #13
CAPACITOR STARTING 1 REFER TO #13
8 TRANS POWER 1 REFER TO #16
9 3010519200 BOX M-PCB PP 1
10 PCB MAIN AS N808 1 REFER TO #17
11 HARNESS RUN CONN 1
12 3012905501 HINGE *M T3.2 PO 1
13 3014901820 SHAFT *M HI S20C 1
14 3016001230 SPECIAL BOLT M T1 TRS 4 X 2 MFZN 3
15 3011424700 COVER *M HI 1
16 3012905600 HINGE *U 1
17 3016005300 SPECIAL WASR 1
18 3016001230 SPECIAL BOLT T/U T1 TRS 4 X 22 MFZN 3
19 3016500710 CASTER F *L AS 1
20 3016000700 SPECIAL SCREW M5 X 15 2
21 3012102500 FOOT ADJ *L AS 1
22 3016500810 CASTER F *R AS 1
23 3012101500 FOOT ADJ AS 1
24 3011439300 COVER CAB BRKT PP 1
25 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 2
26 CORD POWER AS 1 REFER TO #19
27 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 7
29 3013202400 HOSE DRN AS PP 1
30 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 6
31 3012400901 GRILL AS 1
