67 3010519200 BOX M-PCB PP 1
68 TRANS POWER 1
69 HARNESS RUN CON 1
70 PCB MAIN AS N808 1 REFER TO #17
71 CAPACITOR RUN 1
72 3011444900 COVER M-PCB PP 1
73 7122401211 SCREW TAPPING
T2S TRS 4 X 12 MFZN
2
74 3012904800 HINGE *M AS T3.2 SCP-1 1
75 3016001220 SPECIAL BOLT *M
6 X 20 SWCH 22A
3
76 3011424700 COVER *M HI ABS 1
77 3010310900 BASE COMP SBHG1-R 1
78 3016500000 CASTER *R PP 2
79 4018S48121 SHAFT CASTER SWRM-10 2
80 3016003300 SPECIAL BOLT
T2 6.5 X 20
4
81 3011119400 CASE VAPORI PP 1
82 3015906800 MOTOR C BLDC 12V 1 REFER TO #14
83 3011800400 FAN OD 110 (ABS) 1 REFER TO #14
84 3011200500 CLAMP FAN SUS304 1
85 3012004400 FIXTURE C MOTOR SUS 1
85-1 3010102100 ABSORBER C MOTOR NR 1
86 3014426910 PLT CON AS
OD4.76 • T0.7 X L
1
87 7112401211 SCREW TAPPING
T1 TRS 4 X 12 MFZN
2
88 3011444800 COVER C FAN PP 1
89 7112401011 SCREW TAPPING
T1 TRS 4 X 10MFZN
1
90 7122401211 SCREW TAPPING
T2 TRS 4 X 12MFZN
1
91 COMPRESSOR 1 REFER TO #11
92 3010101440 ABSORBER COMP AS NR H40 2
93 3010100201 ABSORBER COMP 2
94 3016002500 SPECIAL WASR T0.7 SK-5 4
95 SWITCH RELAY AS 1 REFER TO #12
96 3012610000 CLAMP BAND RELAY T0.7 SK-5 1
97 DRYER AS 1 REFER TO #17
98 3013201900 HOSE DRAIN B PP 1
99 CORD POWER AS 1
101 7001400865 SCREW MACHINE
T1 PAN 4 X 8 BSN1
1
102 3010103700 ABSORBER SUC P NR 1
103 3012400100 GRILL SBHG-1 1
104 7112401211 SCREW TAPPING
T1 TRS 4 X 12 MFZN
6
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
R
R
R
R
R
R
EXPLODED VIEW AND PARTS LIST
