7
AIR FLOW DIAGRAM
3. FR-630,662,700NT/NB
Freezer
Pleas don’t put bottles such as beer,
beverage etc.
It might be broken because of freezing.
Freezer pocket
Please don’t put long term storing
items such as ice cream etc.
It might be melted because of
opening the door freguently.
Chilled room
It is good for the storage of
fishes and meats.
Crisper
It is suitable to store vegetable and
fruit.
The moisture panel which is attached
to the cover humidity properly.
Vegetable and fruit would be better to be
parked with clean wrap foils.
Inlet of cooling air
It should not be blocked with
food etc. as it is the inlet where
cooling air returns.
Multiple outlet of cooling air.
Please don’t put in vegetable etc. which
contain moisture. It might be frozen
because of low temperature.
To Next Page
