Daewoo FR-521 - Width

29
32 3014426920 PLATE CONN AS 1
33 3010102100 ABSORBER C MOTR 1
34 3012004400 FIXTURE C MOTOR 1
35 MOTOR C 1 REFER TO #14
36 3011800400 FAN 1
37 3011200500 CLAMP FAN 1
38 3011444800 COVER C FAN 1
39 DRYER AS 1 REFER TO #17
40 3011119200 CASE VAPORI PP 1
41 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 2
42 COMPRESSOR 1 REFER TO #11
43 3016002500 SPECIAL WASR SK-5 1
44 SWITCH P-RELAY AS 1 REFER TO #12
45 3012610000 RELAY BAND SK-5 1
46 3012003000 BASE COMP AS 1
47 3016003300 SPECIAL BOLT MFZN 4
48 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 2
49 3012007800 FIXTURE MOTR A PP 2
50 MOTOR R DC MOTOR 1 REFER TO #15
51 MOTOR F DC MOTOR 1 REFER TO #14
52 3018908000 LOUVER F B FRB-5070NB 1
53 3014524800 PLATE SENS 1
54 3011800400 FAN ABS 2
54 3018904201 LOUVER F B PP 1
55 3013333900 INSU F LUVR A 1
56 3018907900 LOUVER F A HIPS 1
57 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 4
58 3010924600 CAP F LUVR 1
59 3017810702 SHELF F 5070NB/KB 1
3017810802 SHELF F 5270NB/KB 1
3017810502 SHELF F 5570NB/KB 1
60 3010621500 BRACKET F SHELF 1
61 7112401211 SCREW TAPPING T1 TRS 4 X 12 MFZN 3
62 3011110200 CASE ICING PP 2
63 3012603400 HANDLE ICE BOX ABS 1
64 3011415500 COVER ICE BOX GPPS 1
65 3010519600 BOX ICE HIPS 1
66 3012003800 FIXTURE F LAMP 1
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
EXPLODED VIEW AND PARTS LIST
