EXPLODED VIEW AND PARTS LIST
2. TOTAL PARTS LIST( FR-860NA )
is a commendable part for essential stock.
NO PART CODE PART NAME SPEC QT’Y REMARK
1 3010032910 ASSY CAB URT CFC 1
3010078710 ASSY CAB URT HCFC 1
3 3015302100 SUPPORTER G SHELF *L *R SBHG T1.8 2
5 3015301810 SUPPORTER G SHELF *M SBHG T1.8 1
7-1 7112403008 SCREW TAPPING T1 TRS 4 X 30 6
8 3018100040 SWITCH DOOR 2 BUTTON / 4 PIN 1 REFER TO #17
9 3010903200 CAP SCREW LDPE 1
10 3017900840 SOCKET *F LAMP AS 1
11 3013600030 LAMP AS 1 REFER TO #16
13 7122401611 SCREW TAPPING T2S TRS 4 X 16 MFZN 7
14 3011800400 FAN ABS 1 REFER TO #14
14-1 3015903010 MOTOR R AS DC 12V 1 REFER TO #15
15 3018500100 MOUSE BELL HIPS 1
16 4017Z32233 COVER MOTOR C HIPS 1
17 4017Z08430 ABSORBER MOTOR EPR-B3(H40) 1
18 3018902510 MOTOR F DC 12V 1 REFER TO #14
20 4017Z32244 COVER MOTOR B HIPS 1
21 3013323700 INSULATOR F LOUVER B F-PS 1
22 3013321310 INSULATOR F LOUVER A F-PS 1
23 4017Z29010 BRACKET F SENS SPCC 1
24 2TA40050WH TAPE ALUMINUM
T0.4 X 50mm
0.08
25 3012003800 FIXTURE F LAMP 1
26 3015502600 WINDOW F GP 1
27 3018903910 LOUVER F AS 1
27-1 CABLE TIE 1
27-2 3011410800 COVER W/F PIPE AS PP 1
27-3 3013200600 HOSE W/F AS 220V~240V/50,60Hz 1
3013200610 HOSE W/F AS 110V~127V/60Hz
28 3016901800 DUCT RETURN ABS 1
29 3013332600 INSU R *S *R F-PS 1
30 3018906600 COVER R *S *R PP 1
31 3013332700 INSU R *S *L F-PS 1
32 3010905100 CAP SIDE M/F COVER ABS 2
33 3018906700 LOUVER R *S *L PP 1
34 3011441300 COVER CUBIC AS 4
3011101810 CASE DEO AS 1
R
R
R
R
R
R
