2. TOTAL PARTS LIST(FR-780NT/NB, FR-820NT/NB)
is recommendable part for essential stock.
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
1 3010075610 ASSY CAB URT FRB-5970NB 1
3010075620 ASSY CAB URT FRB-5970NB(HCFC)
2 3010074710 ASSY CAB URT FRB-6370NB 1
3010074720 ASSY CAB URT FRB-6370NB(HCFC)
3 3015302100 SUPPORTER G SHELF *L SBHG T1.8 1
4 3015302200 SUPPORTER G SHELF *R SBHG T1.8 1
5 3015301810 SUPPORTER G SHELF *M SBHG T1.8 1
6 7112403008 SCREW TAPPING
T1 TRS 4 X 30
6
7 3018100020 SWITCH DOOR 2 BUTTON / 4 PIN 1 REFER TO #17
8 3010903200 CAP SCREW LDPE 1
9 3012003800 FIXTURE F LAMP ABS 1
10 3017900840 SOCKET *F LAMP AS 1
11 LAMP AS 15W 1 REFER TO #16
12 3015502600 WINDOW F GP 1
13 7122401611 SCREW TAPPING T2S TRS 4 X 16 MFZN 4
14 3011800400 FAN ABS 1 REFER TO #14
14-1 3015906600 MOTOR R AS BLDC 12V 1 REFER TO #15
15 3018500100 MOUSE BELL HIPS 1
16 4017Z32233 COVER MOTOR C HIPS 1
17 4017Z08430 ABSORBER MOTOR EPR-B3(H40) 1
18 3015905310 MOTOR F BLDC 12V 1 REFER TO #14
19 4017Z08430 ABSORBER MOTOR EPR-B3(H40) 1
20 3011444700 COVER MOTOR B HIPS 1
21 3013323701 INSULATOR F LOUVER B FRB-59,63NB F-PS 1
22 3013334000 INSULATOR F LOUVER A FRB-59,63NB F-PS 1
23 4017Z29100 BRACKET SENS SPCC 1
24 2TA40050WH TAPE ALUMINUM
T0.4X50 mm
0.08
25 3018903820 LOUVER F AS 1
26 7122401611 SCREW TAPPING
T2S TRS 4 X 16 MFZN
2
27 3010924600 CAP F LOUVER HIPS 2
28 3016905000 DUCT RETURN ABS 1
29 3013332600 INSU R *S *R F-PS 1
30 3018906600 LOUVER R *S *R PP 1
31 3013332700 INSU R *S *L F-PS 1
32 3010905100 CAP SIDE M/F COVER ABS 2
33 3018906700 LOUVER R *S *L PP 1
R
R
R
R
R
R
EXPLODED VIEW AND PARTS LIST
