43
MACHINE ROOM
2. FR-780NT/NB, 860NA
NO PART NAME NO PART NAME
1 BASE CAB *B 13 DRYER AS
2 SCREW TAPPING 14 PIPE HOT
3 CORD POWER AS 15 PIPE CONN A
4 SCREW MACHINE 16 PIPE SUC CONN
5 ABSORBER COMP 17 PIPE SUCTION AS
6 COMPRESSOR 18 BAND RELAY
7 ABSORBER COMP AS 19 SWITCH P-RELAY AS
8 WASHER SPECIAL 20 FIXTURE C FAN
9 BASE COMP AS 21 SCREW MACHINE
10 CASE VAPORI 22 MOTOR C AS
11 SCREW TAPPING 23 C FAN
12 HOSE DRN AS
24 PIPE WICON AS
25 COVER C FAN
