34
34 3011441300 COVER CUBIC AS 1
34 3011101800 CASE DEO AS 1
34-1 3011102501 CASE DEO PP 1
34-2 3018700600 DEODORANT 1
3017714600 SEALING DEO F-US 1
34-3 3018700700 DEODORANT SHEET 1
35 3011441100 COVER CUBIC DUCT ABS 4
38 3012505400 GUIDE *L AS 1
39 7122401611 SCREW TAPPING
T2S TRS 4
X
16 MFZN
1
40 7122401611 SCREW TAPPING
T2S TRS 4
X
16 MFZN
1
41 3012505100 GUIDE *R HIPS 1
42 3014700300 ROLLER A POM 1
43 3016003700 SPECIAL WARS 1
44 3016903300 DUCT CHILD AS HIPS 1
45 3011428400 COVER CASE FRESH PP 1
46 3017902310 SOCKET R LAMP AS 240 [V] / 15[W] 2
47 LAMP AS 15W 1 REFER TO #16
48 3015500200 WINDOW R 1
49 LAMP AS 15W 2 REFER TO #16
49 3017810801 SHELF F SAN 1
50 3010621500 BRACKET F SHELF SHHG1 1
51 7122401211 SCREW TAPPING
T2S TRS 4
X
12 MFZN
3
52 3012505800 GUIDE ICING PP 1
53 3011110200 CASE ICING PP 2
54 3010519600 BOX ICE HIPS 1
55 3011445500 COVER ICE BOX GP 1
56 3012603400 HNDL ICE BOX HIPS 1
57 3011109300 CASE CHILD GP 1
58 30100A4200 SHELF GLASS AS FRB-5960NB(T) 4
3018017200 SHELF GLASS AS FRB-6360NB(T) 4
59 3011716700 DOOR CHILD CASE GP 1 REFER TO #17
60 3011432600 COVER V/CASE GP 1
61 3011113900 CASE VEGETB A GP 1
62 3011114100 CASE VEGETB B HIPS 1
63 3014700300 ROLLER A POM 2
64 3011432800 COVER ROLLER A POM 2
65 3014700400 ROLLER B POM 1
66 3012504900 GUIDE *M ABS 1
NO PART CODE PART NAME PART DESCRIPTION QT’ Y REMARK
R
R
R
EXPLODED VIEW AND PARTS LIST
