Daewoo SD-8100 - Power Cord

Product Information
13
Main body (Rear Panel)
DIGITAL AUDIO OUT
R
ANT.IN
ANT.OUT
EURO AV1
EURO AV2/DECODER
L
AUDIO OUT VIDEO OUT
S-VIDEO OUT
!
(^#@
% *&$
! POWER CORD
It is a jack for supplying power to the unit. Connect to
outlet in a wall.
@ DIGITAL OUTPUT (COAXIAL, OPTICAL)
Jack
To enjoy sound quality of theater level in home,
connect this jack with amp or unit embedded with
digital audio decoder.
# S-VIDEO OUT Jack
To obtain better screen quality, connect and use the
unit to TV or monitor inputted from S-VIDEO.
$ AUDIO OUTPUT Jack
% VIDEO OUTPUT Jack
^ EURO AV1 Jack
& EURO AV2/DECODER Jack
* Connection to ANTENNA Cable
( Connection to TV
DVD-Video(PAL) 02.3.15 5:44 PM ˘`13
