Switch Configuration 11
Quickly setting Figure 4-2
【Parameter Description】
Manage the IP address of the
VLAN
Switch’s management in use of
the VLAN
【Instructions】
Native VLAN: as a Trunk, the mouth will belong to a Native VLAN. The so-called Native VLAN,
is refers to UNTAG send or receive a message on the interface, is considered belongs to the
VLAN. Obviously, the interface of the default VLAN ID (PVID) in the IEEE 802.1 Q VLAN ID is
the Native VLAN. At the same time, send belong to Native VLAN frame on the Trunk, must
adopt UNTAG way.
Allowed VLAN list: a Trunk can transport the equipment support by default all the VLAN traffic
(1-4094). But, also can by setting the permission VLAN Trunk at the mouth of the list to limit the
flow of some VLAN can't through the Trunk.
【Configuration Example】
VLAN setting: such as create VLAN 2. Sets the port 8 to Trunk , Native VLAN 2. Step 1
