Switch Configuration 15
【Configuration Example】
Such as: The port is set to 10 M, half duplex, open flow control and cross line sequence and
port state.
Basic settings II Figure 4-9
4.2.2 Port aggregation
In the navigation bar to select "PORT>port aggregation", In order to expand the port
bandwidth or achieve the bandwidth of the redundancy backup, the following picture:
Port aggregation Figure 4-10
【Parameter Description】
Switch can be set up 8 link trunk
group, group_1 to group_8
For each of the members of the
group and add your own port, and
with members of other groups
【Instructions】
Open the port of the ARP check function, the port of the important device ARP, the port of the
VLAN MAC function, and the monitor port in the port image cannot be added!
【Configuration Example】
