Switch Configuration 39
You can enable or disable PoE
function
Configure port priority, when the
load exceeds the maximum
power POE, low priority port
equipment will be dropped
You can specify threshold
You can configure max power of
port
【Configuration Example】
Such as: The PoE function of port 8 can be enabled, the maximum Port power is 23 W,
threshold is 15mA, and the Power supply priority is high.
Configuration example Figure 4-70
4.5.1.2 Temperature distribution
In the navigation bar to select "POE>POE port Config>Temperature distribution", you can view
temperature distribution, As follows.
Temperature distribution Figure 4-71
4.6 STP
In the navigation bar to select "STP", you can set to the MSTP region and STP bridge
configuration.
