Switch Configuration 47
Queue config Figure 4-87
【Parameter Description】
Can choose four kinds of modes:
RR round-robin scheduling
SP absolute priority scheduling
WRR weighted round-robin
scheduling
WFQ weighted fair scheduling
Set the weights of each queue,
they will be in proportion to
occupy the bandwidth to send
data
【Instruction】
Queue 7 cannot for 0.
【Configuration Example】
Such as: set the scheduling strategy for WRR, weight value respectively, 10, 11, 12, 12, 14, 15,
16, 17.
Configuration example Figure 4-88
4.8.2 Mapping the queue
4.8.2.1 COS Queue Map
In the navigation bar to select "QoS>mapping the queue>COS Queue Map", Service
category can be mapped to the corresponding queue. The following picture.
