Dahua Technology DH-PFS4210-8GT-150 User Manual

Switch Configuration 48
COS queue map Figure 4-89
【Parameter Description】
Parameter
Description
Server ID
COS the VLAN priority fields (0 to
7)
Queue ID
Set each cosine value mapping
queue number (0 to 7)
【Configuration Example】
Such as: cos 3 mapping to the queue 7, set the queue weight 7 to 10.
Configuration example I Figure 4-90
Configuration example II Figure 4-91
4.8.2.2 DSCP COS Map
In the navigation bar to select "QoS>mapping the queue>DSCP COS Map", Differential
service can be mapped to the corresponding service categories. the following picture:
