User’s Manual
238
Table 5-59 Wi-Fi connection parameters
Parameter
Description
Connect
Automatically
Enable Connect Automatically.
After the Device is restarted, it will automatically connect to the nearest
hotspot that had been connected successfully.
Refresh
Refresh the hotspot list. The self-adaption function such as adding
password is supported if such setting was once configured.
Connect
In the hotpots list, select a hotspot, and then click
Connect
.
To reconnect the same hotspot, disconnect first and then reconnect.
To connect to other hotspot, disconnect from the current connected
hotspot first, and then connect to the other hotspot.
Disconnect To disconnect from a hotspot, click
Disconnect
.
Click Apply to complete the settings.
After the Device is connected to a Wi-Fi hotspot, in the Wi-Fi Info area, the current hotspot, IP
address, subnet mask, and default gateway are displayed.
5.15.1.4 Configuring 3G/4G Settings
You can connect a wireless 3G/4G module to the USB port of the Device and then access the Device
with the IP address provided by the module.
Not all models support this function.
Connect the wireless 3G/4G module to the USB port of the Device.
Select Main Menu > NETWORK > 3G/4G.

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
