Dahua Technology DH-XVR1B16H User Manual

User’s Manual
319
No.
Icon
Description
7 None
Includes eight function titles:
LIVE
,
VIDEO
,
ALARM
,
IVS
,
IoT
,
BACKUP
,
MAINTAIN
,
DISPLAY
, and
AUDIO
. Click each title to open the configuration
interface of the title.
LIVE
: You can perform the operations such as viewing real-
time video,
configuring channel layout, setting PTZ controls, and using smart talk and
instant record functions if needed.
VIDEO
: Search for and play back the recorded video saved on the Device.
ALARM
: Search for alarm information and configure alarm event actions.
IVS
:
Configure the behavior detections by drawing rules for detecting
tripwire, intrusion, abandoned objects, and missing objects.
IoT
: You can view, search and export the temperature and humidity data of
camera and configure the alarm event settings.
BACKUP
:
Search and back up the video files to the local PC or external
storage device such as USB storage device.
MAINTAIN
: You can view log and system information, test network and do
other maintenance work.
DISPLAY
: Configure the display effect such as displaying content, image
transparency, and resolution, and enable the zero-channel function.
AUDIO
: Manage audio files and configure the playing schedule. The audio
file can be played in response to an alarm event if the voice prompts function
is enabled.

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
