User's Manual
8
Fasten screws
2.2.3 DHI-XVR7416L-4KL
Remove the fixing screws on the rear panel.
Remove screws
Remove the cover along the direction shown in the following arrow.
Remove cover
Remove the screws on the sides of HDD bracket to take out the bracket.
