Dahua Technology DHI-XVR5116HS-S2 User Manual

User's Manual
253
RS-232
Configure the settings for RS-232 port parameters.
Table 5-73 RS-232 parameters
Parameter
Description
Function
In the Function list, select the protocol for the port.
Console: Debug by connecting a mini terminal software.
Keyboard: Control the Device by connecting a dedicated keyboard.
Adapter: Transit data by connecting to PC.
Protocol COM: This function is for card overlay.
NetKeyboard: Control the Device by connecting a dedicated
keyboard to the LAN port.
PTZ Matrix: Connect the video matrix for control.
The default setting is
Console
.
Baudrate
In the
Baudrate
list, select a value for baudrate length. The default
setting is
115200
.
Data Bits In the
Data Bits
list, select
5
,
6
,
7
, or
8
. The default setting is
8
.
Stop Bits In the
Stop Bits
list, select
1
,
1.5
, or
2
.
Parity
In the
Parity
list, select
None
,
Odd
,
Even
,
Mark
, or
Null
. The default
setting is
None
.
Click Apply to complete the settings.
