Dahua 5000 Series User Manual

System Configurations 21
Channel grouping Figure 4-4
Select Input group, and then configure Group name and Time. Step 5
Select the channels that you need. Step 6
Click on the Channel grouping interface to add channels.
Click Save to save the channel group. Step 7
4.1.3 Video on Wall
On the Preview interface, select HDMI1–HDMI4 or VGA5 in drop-down list. Step 1
Select video source on the right, drag it onto TV wall or double-click the video source. Step 2
Quick Video on Wall (Optional)
 Click , and a dialog box pops up. See Figure 4-5. Enter a number (such as 1) + ,
so video of channel 1 will be displayed on wall quickly.
 Click , and a dialog box pops up. See Figure 4-5. Enter channel group number (such
as 123) + , so videos of the channel group No. 123 will be displayed on wall quickly.
