Dahua 5000 Series - TV Wall Icon Description

System Configurations 39
TV wall (screen information) Figure 4-30
Switching Main and Sub-stream
Click to switch main and sub-stream. M represents main stream, while S represents
sub-stream.
Please switch the stream, and then drag the video onto the TV wall.
Clearing Screen
Click to clear screen.
4.3.5 TV Wall Icon Description
Refer to Table 4-5 for icon description.
Table 4-5 Icons of TV wall interface
Icon
Description
Icon
Description
Refresh
Configure TV wall
Clear screen
Return
Maximize and restore the window
Single split
4-split
9-split
