Dahua 5000 Series User Manual

System Configurations 31
Parameter
Description
Resolution
Select resolution.
When video resolution is ﹥ the set resolution, snapshot image adopts

the set resolution.
When video resolution is ﹤ the set resolution, snapshot image adopts

actual video resolution.
USB|FTP
Select FTP.
Address
Set FTP address.
User Name
FTP user name.

Password
FTP login password.

Directory
Set directory name.

Test
Click this button to test whether FTP is available.

Click OK. Step 5
4.1.10 Playback of Recorded Videos
This function is supported by NVR devices that have recorded videos, rather than IVSS device.
On the Preview interface, click . Step 1
The Playback interface is displayed. See Figure 4-18.
Playback Figure 4-18
Select playback device and channel, configure time and click Playback. Step 2
The system starts to play back recorded videos. See Figure 4-19.
