Dahua 5000 Series User Manual

System Configurations 54
Call Figure 4-48
Enter a number in the input box, such as 1. Click Preset to call the preset point 1.
 It will be called successfully after you have set preset point.
 Call methods of scan, tour and pattern are the same as that of preset point. Refer to "4.5.2
Settings" for details.
4.5.2 Settings
4.5.2.1 Settings of Preset Point
Turn the camera to required position with the joystick or direction button. Step 1
Select Preset. Step 2
Enter a preset point value in Preset input box, such as 1. Step 3
Click Settings. Preset point 1 is set successfully. Step 4
4.5.2.2 Settings of Tour
Select Tour. Step 1
Enter tour route value in Tour No. input box. Step 2
Enter a preset point value in Preset input box, and then click Add Preset to add a Step 3
preset point to the tour route.
 Multiple preset points can be added.

Dahua 5000 Series Specifications

General

Brand	Dahua
Model	5000 Series
Category	Keyboard
Language	English
