HDCVI Series DVR User’s Manual
Figure 4-13
In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure 4-14.
Please make sure your protocol supports this function and you need to use mouse to control.
Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust
section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ automatically. The
smaller zone you dragged, the higher the speed.
Figure 4-14
In Figure 4-13, click to open the menu, you can set preset, tour, pattern, scan and etc. See
Figure 4-15.
Figure 4-15
Please refer to the following sheet for detailed information.
Please note the above interface may vary due to different protocols. The button is grey and can not
be selected once the current function is null.
Right click mouse or click the ESC button at the front panel to go back to the Figure 4-13.
