12
Figure 3-7
Step 2 Set the parameters. Please refer to Table 3-4.
Select protocol type. It only supports “Private” at present.
Enter start IP and end IP when one IP segment is added.
Enter start IP when one IP is added.
Enter port number. It is usually default value.
Enter username and password.
Enter channel quantity. means that it is opened, while
means that it is closed.
For example, total channel quantity of the device is 48.
However, if you want to add 1
st
channel ～16
th
channel, set the
channel quantity.
Table 3-4
Step 3 Click “OK”.
3.5.3 Auto Search
Step 1 Enter “Device Manage” interface and click . The system pops out dialog box of auto
search, as shown in Figure 3-8.
