44
Appendix 1 Technical Parameters
10.1 inch TFT LCD screen, 1280×800 resolution
10.1 inch capacitance screen, 1280×800 resolution
1 LCD screen and 4 HDMI ports. There are 5 output ports in total.
[Stream type] Support H.265, H.264, H264H, H264B, MJPEG, SVAC,
SmartH.264 and non-standard stream.
[Decoding performance] Support hardware decoding, 1200W/4K/1080P
[Split performance] At present, single screen supports max. 16-split, so 5
screens support 80-split in total.
1 audio input, 3.5mm stereo, support voice intercom function.
1 audio output, 3.5mm stereo
1 loudspeaker to play audios.
Two 100M/1000M self-adaptive Ethernet ports
4 USB ports, including 2 USB2.0 ports and 2 USB3.0 ports
2, as ordinary serial port (debugging), to control the recorder and other
devices
Host: 425mm×194mm×59mm (length × width× height, excluding joystick
/ antenna)
Keyboard: 421mm×105mm×26mm (length × width× height)
Appendix Table 1-1 Technical Parameters
