36
Figure 8-3
Step 2 Set the parameters. Please refer to Table 8-1 for details.
In case of serial port control, identify devices according to the address.
Value ranges from 0 to 255.
Baud rate ranges from 1200 to 115200. There are 8 levels available.
Select data bit, including 5, 6, 7 and 8.
Select stop bit, including 1 and 2.
Select parity, including none, odd, even, checkmark and null parity.
Table 8-1
Step 3 Click “OK”.
8.2.5 General
Set name, date and time etc. of internet keyboard.
Step 1 At “General” interface, click “General” tab to enter “General” interface, as shown in
Figure 8-4.
