Dahua NVR4832-I User Manual

Front Panel and Rear Panel 9
No.
Port Name
Function
8
MIC IN
Bidirectional talk input port. It is to receive analog audio
signal from devices such as microphone, sound pickup.
MIC OUT
Audio output port. It is to output analog audio signal to
devices such as sound box.
 Bidirectional talk output.
 Audio output on 1-window video monitor.
 Audio output on 1-window video playback.
9
USB port
USB3.0 port. Connect to devices such as mouse, USB
storage device and USB burner.
10
Network port
10M/100M/1000Mbps self-adaptive Ethernet port. Connect
to the network cable.
11
Power input port
Input power of 100V-240V and 50Hz-60Hz.
12
GND.
2.2.3 NVR52-16P-I/52-8P-I/42-16P-I Series
These figures are for reference only. The actual product shall prevail.
Figure 2-5 NVR5216-16P-I
Figure 2-6 NVR5216-8P-I
